POWER PARAMETERS

Power input:100-240VAC/50-60Hz/1.2A

Power output: 25.2DC/2A

Lithium battery capacity: 900mAh

BEAM LIMITER PARAMETERS

Output focal distance: 200mm

Output radiation range:φ5mm

TUBE HEAD PARAMETERS

Power input:25.2DC/10A

Tube voltage/current:60kv/2mA

Output power:120W

Working frequency: 80KHz

Exposure time:0.1-2.0s

X-RAY TUBE PARAMETERS

Maximum working tube voltage:70Kvp

Filament characteristics:3±0.5V/2.5A

Nominal value of focus:0.4mm

Bevel angle of target surface:12°

Inherent filtration capacity:≥0.75mmAl
